PCR Thermal Cyclers

Introduction

For over 10 years we have specialized in thermal cyclers with proven performance and unmatched combination of features. Just right for every laobratory, whether you run only a few samples per week or perform high-through processes. Thousands of our products are in daily use around the globe, helping secientists, health professionals and laoboratory managers achieve high levels of accuracy and consistency in their work. We believe in giving our customers a choice in how they use our thermal cyclers, supported by excellent service and support.

Which thermal cycler instrument is right for you?

Model
Appearance
Block Formats 96×0.2ml(A),54×0.5ml(B),96×0.2ml+77×05ml(C),384well(D) 64×0.2ml(A),36×0.5ml(B) 30×0.2ml(A),9×0.5ml(B),
16×0.2ml+9×0.5ml(C)
Temp Range 0℃~99.9℃ 0℃~99.9℃ 0℃~99.9℃ 0℃~99.9℃ 4℃~99.9℃ 0℃~99.9℃
Display Interface 7'LCD 5.7'LCD 5.7'LCD 5.7'LCD 4.3'LCD 12864LCD
Max.Heating Ramp Rate 5.0℃/s 4.5℃/s 4.0℃/s 4.0℃/s 2.5℃/s 2.0℃/s
Max.Cooling Ramp Rate 5.0℃/s 4.0℃/s 3.5℃/s 3.5℃/s 2.5℃/s 2.0℃/s
Heating/Cooling adjustable rate 0.1℃/s~4.0℃/s 0.1℃/s~4.0℃/s 0.1℃/s~4.0℃/s 0.1℃/s~4.0℃/s - -
Uniformity ≤±0.2℃ ≤±0.2℃ ≤±0.2℃(20~75℃) ≤±0.2℃(20~75℃) - ≤±0.3℃(20~75℃)
Accuracy ≤±0.1℃ ≤±0.1℃ ≤±0.2℃ ≤±0.2℃ ≤±0.2℃ ≤±0.2℃
Gradient Temp Range 30~99℃ 30~99℃ 30~99℃ - - -
Thermal Gradient Span 1~30℃ 1~30℃ 2~30℃ - - -
Gradient Uniformity ≤0.2℃(single row) ≤0.2℃(single row) ≤0.2℃(single row) - - -
Hot Lid Temp 20~110℃ 20~110℃ 30~115℃ 30~115℃ - -
Temp Control Mode Block,tube* Block,tube* Block,tube Block,tube Block Block
Memory Capacity 2000** 1000** 200 200 9 3
Max.No.of Cycle 999 999 99 99 99 99
Communication USB2.0/RS 232/RJ45 USB2.0/RS 232/RJ45 USB2.0/RS 232 USB2.0/RS 232 - Serial port
Intelligent Diagnosis 108 108 - - - -
Size(W×D×H,mm) 380×270×250 380×270×250 380×270×250 380×270×250 370×260×290 160×140×120
Weight(kg) 8.1 7.8 7.2 7.2 4.9 2.2
Learn More Learn More Learn More Learn More Learn More Learn More

Literature

Solutions Support

Heal Force thermal cycler brochure (English)

Real-time PCR Instrument (English)

Thermal Cycler 2015 presentation.pptx (English)

PCR in Crime Scene investigation Access to our expert service team, information on support plans, parts and consumables resources, and other instrument services
